QuickJack 5000TLX-220V

$1,875.00
SKU:
5175637

Product Description

5000TLX is an extended-length lift with jack support locations that extend 6 inches farther than our TL models. QuickJack is the best car lift for your home garage or shop, and with the additional reach of the EXT, you'll service more vehicles than ever. Great for light-duty trucks and SUVs.

Product Info

Assembly Required:
true
Brand:
QuickJack
Category:
/Car Lifts/Frame Engaging Lifts/
Color:
Black
Material:
Steel
Product Type:
Frame Engaging Lift
Rated For Outdoor Use:
false
Safety Lock Equipped:
true
SKU:
5175637
Whats Included Description:
  • 1 Set of 5000TLX-220V Left and Right Frames
  • 1 5000TLX-220V Power Unit

Technical Specifications

Amps:
5
Motor:
208-240V, 50-60 Hz, 1-Ph.
Voltage:
208-240V
Watts:
220

Shipping Info

Business Days To Drop Ship:
5
Free Shipping To Customer:
true
Freight Class:
70
How Many Packages Does This Product Ship In:
3
How This Item Normally Ship:
Parcel
Installation Fees:
1
Offload Requirement:
None
Package 1 Shipping Dimensions Comb Units:
80 x 16 x 24 / 100 lbs.

Product Dimensions

Height Range:
20.504"
Height Overall Comb Units:
20.5" / 521 mm
Lifting Height Stacked blocks Comb Units:
23.75" / 603 mm
Lifting Height With 2 inch block Comb Units:
20.75" / 527 mm
Lifting Height With 3 inch block Comb Units:
21.75" / 552 mm
Lowered Height Frame Only Comb Units:
2.75" / 70 mm
Lowered Height With 2 inch block Comb Units:
3.38" / 86 mm
Overall Length Comb Units:
76" / 1930 mm
Overall Width Max Comb Units:
11" / 279 mm

Marketing Info

General Description 50:
QuickJack 5000TLX Extended-Length Portable Car Lift

Features

Compatibility Feature Benefit:
Automatic safety locks
Feature Benefit 1:
Increased lifting height
Feature Benefit 2:
One-handed operation
Feature Benefit 3:
Accessories to increase versatility

Regulatory Compliance

Nmfc No Spaces No Preceding Zeros No Dashes:
111220
Return Disposition:
Return to Vendor

Parts

Serviceable Parts 1:
5716192 QUICKJACK POLYURETHANE WHEEL
Serviceable Parts 2:
OFFSET CYLINDER ASSEMBLY Ø1.5 x 18.559in
Serviceable Parts 4:
5300862 3" Tall Blocks
Serviceable Parts 5:
5570233 Short Hose 39.5 (1005 mm)
Serviceable Parts 6:
5570216 Long Hose 148.25 (3734 mm)
Serviceable Parts 7:
5210260 Schrader valve Set of 2
Serviceable Parts 8:
5550308 Quick-Connect Hose Fitting Set

Warranty

Warranty Period In Months:
12
Warranty Period In Months Required Unless Lifetime Warranty Lift Structure:
12
Warranty URL:
/support/warranty/
